Applications
Pharmaceutical, Chemical, Petrochemical, Refinery, Paper, & Pulp, Sugar, Breweries, Food & Beverages, Cement Industries, etc
Pressure Range Selection
-50 to + 50° C, 0 to 60° C, 0-100° C, 0-150° C, 0-200° C, 0-300° C, 0-400° C, 0-500° C, 0-600° C, 0-650° C, or in Farehiet Scale as required
4How to Inquire:
Send you inquiry with details like :
Type: Fixed Stem type or capillary type
Dial size: 100mm or 150mm
Temperature range: any std range in C or F
Thread connection : 1/2" or 3/4" bsp or npt
Mounting : back or bottom
Stem length : 10" or 12" or other
Stem diameter: 9.5mm, 10mm or 12mm
Capillary: (if required) 3 meter is standard or other
Filling: dry or liquid filled
Thermowell requirement
or any other special requirements you have.
Send Email to 4 sales@adarshpressuregauge.com or 4Click here to send inquiry by online form Or Call +91-22-29275496 Fax +91-22-29275558
Gas Filled Thermometer
ZG Series
ZGR
Rigid Stem Type
ZGC
Capillary Type
Address:
Adarsh Industries
307, Shankala Industrial Estate,
Gogatewadi, Off Aarey Road,
Goregaon East,
Mumbai - 400063
India
Tel: +91-22-29275496, Fax: +91-22-29275558
Gas Filled thermometers are suitable for all industrial applications from ranges -50 to 600 deg C in dial sizes 100mm, 150mm, 200mm and 250mm. Available in all Stainless Steel Construction with option of silicon filling for vibration applications. Also as nitrogen is used inside the thermometer they are also suitable for hygenic applications. They are available in both stem type for local mounting in bottom or back mounting as well as for distance or remote temperature sensing with capillary length upto 25 meters. These thermometers are designed in such a way that there is least change in error with changes in ambient temperature. Also Electrical contacts are available for dial sizes 4" and 6". Other options include Armour capillary, thermowells (protection tubes).
